| Shank Size (SS) | HSK A 100 | Application | | Face contact interface | |
| Connection Size (CSI) | ER50 | Tool Type | HSK |
| Body Diameter (BD) | 78 mm | Connection Diameter Minimum Workpiece Side (DCONNWS) | 10 mm |
| Body Length (LB) | 71 mm | Connection Diameter Maximum Workpiece Side (DCONXWS) | 34 mm |
| Connection Diameter Machine Side (DCONMS) | 100 mm | Measurement Type | Metric |
| Shank Length (LS) | 50 mm | Body Material | Steel |
| Functional Length (LF) | 100 mm | Unit | M |
Product Features
| Family Description | ER collet chucks with HSK-A shank | FamilyName | HSK A-ER (collet chuck) |
| COO | ITALY | BrandName | Tungaloy |
Shipping Info
Weight per item
0.0000
Name
Collet Chucks
FamilyName
HSK A-ER (collet chuck)
BrandName
Tungaloy
