| Application | | Slot Milling | | Flute Helix Angle (FHA) | 0 Degrees |
| Cutting Diameter (DC) | 25 mm | Grade | GH730 |
| Applicable Material | | Steel | Stainless Steel | | Coating | TiCNO |
| Flute Count (NOF) | 6 | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Corner Radius (RE) | 0.4 mm | Measurement Type | Metric |
| Cutting Diameter Maximum (DCX) | 25 mm | Cutting Edge Material | Carbide |
| Depth of Cut Maximum (APMX) | 8 mm | Tool Type | Solid "T" slot cutters |
| Cutting Width (CW) | 8 mm | Body Material | Carbide |
| Functional Length (LF) | 8.4 mm | Unit | M |
Product Features
| Family Description | Slotting, 6 flutes, for T-slotting | FamilyName | VTB-06 |
| Remarks | Torque: Recommended torque (Nm) for clamping. | BrandName | Tungaloy |
| COO | ISRAEL |
Shipping Info
Weight per item
0.0000
Name
Solid End Mill Heads
FamilyName
VTB-06
BrandName
Tungaloy
